MP9900
Image Platform with Built-in AI Chip
Features
Use self-developed AI Engine, fully upgrade scanning performance
Best in motion tolerance up to 8m/s
Smart soft white LED offer convenient and comfortable user experience
Solid-state electronics for silent operation and superior reliability
Functions
Title Here
Title Here
Title Here
Title Here
Title Here
Title Here
Key Features
Dimensions
152.8 mm × 81.6 mm × 145.1 mm (without stand)
152.8 mm × 112 mm × 186.6 mm (with stand)
Weight
152.8 mm × 81.6 mm × 145.1 mm (without stand)
152.8 mm × 112 mm × 186.6 mm (with stand)
Weight
482 g (without stand, without cable)
755 g (with stand , without cable)
Cable Straight 2.0 m
Connector Type RJ-45 phone jack connector
Case Material PC
Exit Window Material Tempered glass
Indicator Interface Beeper and LED
Host System Interfaces RS-232, or USB Keyboard, USB virtual COM
Trigger Mode Continue
Programming Method Scanning special barcodes in sequence
Firmware Upgrade Online
755 g (with stand , without cable)
Cable Straight 2.0 m
Connector Type RJ-45 phone jack connector
Case Material PC
Exit Window Material Tempered glass
Indicator Interface Beeper and LED
Host System Interfaces RS-232, or USB Keyboard, USB virtual COM
Trigger Mode Continue
Programming Method Scanning special barcodes in sequence
Firmware Upgrade Online
ELECTRICAL CHARACTERISTICS
Input Voltage 5.0 ± 0.25 VDC
Current Scanning: 450 mA (Max:800 mA); Standby: 300 mA
PERFORMANCE CHARACTERISTICS
CPU 32-bit ARM Microprocessor
Scan Pattern Image
Image Size 1280 × 1024 pixels
Light Source 2700 K , white LED
Scanning Angles ±60°, ±54°, 360°(skew, pitch, roll)
Motion Tolerance 8m/s (315 inches/second)
Field of View Horizontal: 40°, vertical:32°
Print Contrast 20% minimum reflectance difference
Minimum Resolution 4 mil
Decoding Capability All common 1D/2D paper barcodes and mobile barcodes
Decoding Depth
- 4 mil Code39（3 chars） 60 mm – 80 mm
- 5 mil Code128（12 chars） 50 mm – 110 mm
- 13 mil UPC（6 chars） 5 mm – 180 mm
- 20 mil Code39（3 chars） 20 mm – 220 mm
- 10mil QR（20 chars） 40 mm – 130 mm
- 20mil QR（20 chars） 10 mm – 180 mm
- 20mil QR（150 chars） 10 mm – 180 mm
Key Features
| Product Details | Specifications |
|---|---|
| Type of Operation | Auto (Conveyor Scanner) |
| Speed | 2 m/s |
| Connectivity Type | Wired(USB) |
